Fortinet FortiGate 600F (FG-600F) – Thiết bị tường lửa
Liên hệ
- Dành cho mạng 600-800 người dùng
- Threat Protection Throughput: 10.5 Gbps
- Site-to-Site VPN Tunnels: 2000
- 7.8 triệu phiên đồng thời
Mô tả
Thuộc Tính
Description
Fortinet FortiGate 600F (FG-600F) là thiết bị tường lửa dành cho mạng 600-800 người dùng với 4x 25G SFP28 slot, 4 x 10GE SFP+, 18 x GE RJ45port (bao gồm 1 x cổng MGMT, 1 cổng X HA, 16 x switchport), 8 x khe cắm GE SFP, tăng tốc phần cứng SPU NP7 và CP9, nguồn điện AC kép. Nó có Threat Protection Throughput: 10.5 Gbps, Site-to-Site VPN Tunnels: 2000, 7.8 triệu phiên đồng thời.
Xem thêm: fortigate-600f-series-datasheet
Thông số kỹ thuật của Fortinet FortiGate 600F (FG-600F) – Thiết bị tường lửa
| Interfaces and Modules | ||
| Hardware Accelerated GE RJ45 Interfaces | 16 | |
| Hardware Accelerated GE SFP Slots | 8 | |
| Hardware Accelerated 10GE SFP+ Slots | 4 | |
| Hardware Accelerated 25GE SFP28/ 10GE SFP+/ GE SFP Ultra Low Latency Slots | 4 | |
| GE RJ45 MGMT/HA Ports | 2 | |
| USB Port | 2 | |
| RJ45 Console Port | 1 | |
| Onboard Storage | 0 | |
| Included Transceivers | 2x SFP (SX 1 GE) | |
| System Performance — Enterprise Traffic Mix | ||
| IPS Throughput | 14 Gbps | |
| NGFW Throughput | 11.5 Gbps | |
| Threat Protection Throughput | 10.5 Gbps | |
| System Performance and Capacity | ||
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 139 / 137.5 / 70 Gbps | |
| IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 139 / 137.5 / 70 Gbps | |
| Firewall Latency (64 byte, UDP) | 4.12 μs | |
| Firewall Throughput (Packets Per Second) | 105 Mpps | |
| Concurrent Sessions (TCP) | 7.8 Million | |
| New Sessions/Second (TCP) | 550,000 | |
| Firewall Policies | 10,000 | |
| IPsec VPN Throughput (512 byte) | 55 Gbps | |
| Gateway-to-Gateway IPsec VPN Tunnels | 2000 | |
| Client-to-Gateway IPsec VPN Tunnels | 50,000 | |
| SSL-VPN Throughput | 4.3 Gbps | |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 2500 | |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 9 Gbps | |
| SSL Inspection CPS (IPS, avg. HTTPS) | 7500 | |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 840 000 | |
| Application Control Throughput (HTTP 64K) | 32 Gbps | |
| CAPWAP Throughput (HTTP 64K) | TBA | |
| Virtual Domains (Default / Maximum) | 10 / 10 | |
| Maximum Number of FortiSwitches Supported | 96 | |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 1024 / 512 | |
| Maximum Number of FortiTokens | 5000 | |
| High Availability Configurations | Active / Active, Active / Passive, Clustering | |
| Dimensions | ||
| Height x Width x Length (inches) | 1.75 x 17.0 x 15.0 | |
| Height x Width x Length (mm) | 44.45 x 432 x 380 | |
| Weight | 15.6 lbs (7.1 kg) | |
| Form Factor | Rack Mount, 1 RU | |
| AC Power Consumption (Average / Maximum) | 169 W / 255 W | |
| AC Power Input | 100–240V AC, 50/60Hz | |
| AC Current (Maximum) | 6A@100V | |
| Heat Dissipation | 871 BTU/h | |
| Redundant Power Supplies (Hot Swappable) | Yes | |
| Operating Environment and Certifications | ||
| Operating Temperature | 32–104°F (0–40°C) | |
| Storage Temperature | -31–158°F (-35–70°C) | |
| Humidity | 5–90% non-condensing | |
| Noise Level | 55 dBA | |
| Airflow | Side and Front to Back | |
| Operating Altitude | Up to 7400 ft (2250 m) | |
| Compliance | FCC Part 15 Class A, RCM, VCCI, CE, UL/ cUL, CB |
|
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN, USGv6/IPv6 | |
