| Interfaces and Modules |
|
| Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots |
2 |
| Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots |
8 |
| Hardware Accelerated 10 GE SFP+ / GE SFP Slots |
16 |
| Hardware Accelerated 10 GE / 5 GE / 2.5 GE / GE / 100M RJ45 Slots |
8 |
| 2.5 GE / GE HA Port |
1 |
| 10GE/ GE RJ45 Management Ports |
1 |
| USB Ports (Client / Server) |
2 / 2 |
| Console Port |
1 |
| Onboard Storage |
0 |
| Trusted Platform Module (TPM) |
Yes |
| Included Transceivers |
2x SFP SX |
| System Performance — Enterprise Traffic Mix |
|
| IPS Throughput |
19 Gbps |
| NGFW Throughput |
15 Gbps |
| Threat Protection Throughput |
13 Gbps |
| System Performance and Capacity |
|
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
198 / 196 / 134 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
198 / 196 / 134 Gbps |
| Firewall Latency (64 byte, UDP) |
3.45 μs |
| Firewall Throughput (Packets Per Second) |
201 Mpps |
| Concurrent Sessions (TCP) |
7.5 Million |
| New Sessions/Second (TCP) |
650 000 |
| Firewall Policies |
100 000 |
| IPsec VPN Throughput (512 byte) |
55 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
20 000 |
| Client-to-Gateway IPsec VPN Tunnels |
100 000 |
| SSL-VPN Throughput |
5.3 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
10 000 |
| SSL Inspection Throughput (IPS, avg. HTTPS) |
10 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
11 000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
600 000 |
| Application Control Throughput (HTTP 64K) |
44 Gbps |
| CAPWAP Throughput (HTTP 64K) |
65 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 250 |
| Maximum Number of FortiSwitches Supported |
196 |
| Maximum Number of FortiAPs (Total / Tunnel) |
4096 / 1024 |
| Maximum Number of FortiTokens |
20 000 |
| High Availability Configurations |
Active-Active, Active-Passive, Clustering |
| Dimensions |
|
| Height x Width x Length (inches) |
3.5 x 17.44 x 17.63 |
| Height x Width x Length (mm) |
88.9 x 443 x 447.4 |
| Weight |
21.94 lbs (9.95 kg) |
| Form Factor (supports EIA/non-EIA standards) |
Rack Mount, 2RU |
| AC Power Supply |
100–240V AC, 50/60Hz |
| AC Current (Maximum) |
6A@120VAC, 3A@240VAC |
| Power Consumption (Average / Maximum) |
210 W / 408 W |
| Heat Dissipation |
1211 BTU/h |
| Power Supply Efficiency Rating |
80Plus Compliant |
| Redundant Power Supplies (Hot Swappable) |
Yes
(comes with 2PSU default) |
| Operating Environment and Certifications |
|
| Operating Temperature |
32–104°F (0–40°C) |
| Storage Temperature |
-31–158°F (-35–70°C) |
| Humidity |
10–90% non-condensing |
| Noise Level |
66.7 dBA |
| Forced Airflow |
Front to Back |
| Operating Altitude |
Up to 10,000 ft (3048 m) |
| Compliance |
FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB |
| Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN, USGv6/IPv6 |
