Fortinet FortiSwitch Rugged 124D (FSR-124D) – Thiết bị chuyển mạch
Liên hệ
- 16x GE RJ45
- 4x GE SFP,
- 8x cặp phương tiện chia sẻ (bao gồm 8x GE RJ45, 8x GE SFP)
- Tương thích với bộ điều khiển chuyển đổi FortiGate
Mô tả
Thuộc Tính
Description
Fortinet FortiSwitch Rugged 124D (FSR-124D) là thiết bị chuyển mạch L2 với 16x GE RJ45, 4x GE SFP, 8x cặp phương tiện chia sẻ (bao gồm 8x GE RJ45, 8x GE SFP), tương thích với bộ điều khiển chuyển đổi FortiGate
Xem thêm:
Thông số kỹ thuật của Fortinet FortiSwitch Rugged 124D (FSR-124D) – Thiết bị chuyển mạch
|
Mã sản phẩm |
FSR-124D |
| Ethernet | |
| Ethernet Interface | - 16x GE RJ45 ports - 4x GE SFP slots - 8 shared media interfaces (GE RJ45 / GE SFP slots) |
| Console Interface | DB9 connector |
| Operating Mode | Store and forward, L2/L3 wire-speed/non-blocking switching engine |
| MAC Addresses | 8K |
| Switching Capacity | 56 Gbps |
| Packets Per Second | 83 Mpps |
| VLANs Supported | 4K |
| DRAM | 512 MB |
| FLASH | 512 MB |
| Copper RJ45 Ports | |
| Speed | 10/100/1000 Mbps |
| MDI/MDIX Auto-crossover | Support straight or cross wired cables |
| Auto-negotiating | 10/100/1000 Mbps speed auto-negotiation; Full and half duplex |
| PoE+ (PSE) | – |
| SFP (pluggable) Ports | |
| Port Types Supported | Gigabit fiber multimode, fiber single mode, fiber long-haul single mode 1000Base(SX/LX/ZX) |
| Fiber Port Connector | LC typically for fiber (depends on module) |
| Power | |
| Power Input | Redundant input terminals |
| Input Voltage Range | +48V DC |
| Reverse Power Protection | – |
| Power Consumption (Maximum) | 25.434 W (Without PoE/PoE+) |
| Heat Dissipation | 117.49 BTU/h |
| Indicators | |
| Power Status Indication | Indication of power input status |
| PoE Indication | – |
| Ethernet Port Indication | Link and speed |
| Environment | |
| Operating Temperature Range | -40–185°F (-40–85°C) |
| Storage Temperature Range | -40–185°F (-40–85°C) |
| Humidity | 10–95% RH non-condensing |
| MTBF | > 30 years |
| Cooling | Fanless |
| Certification and Compliances | |
| EMI | Radiated Emission: CISPR 22, EN55022 Class B Conducted Emission: EN55022 Class B |
| EMS | ESD: IEC61000-4-2 Radiated RF (RS): IEC61000-4-3 EFT: IEC61000-4-4 Surge: IEC61000-4-5 Conducted RF (CS): IEC61000-4-6 |
| RoHS and WEEE | Compliant |
| FCC | Yes, with supplementary IEEE 1613 |
| CE | Yes, with supplementary IEC 61850-3 |
| Others | ICES, RCM, VCCI, BSMI, CB, UL/cUL |
| Mechanical | |
| Ingress Protection | IP40 |
| Installation Option | Rack mount |
| Dimensions | |
| Length x Width x Height | 17.40 x 13.86 x 1.73 inches (442 x 352 x 44 mm) |
| Weight | 12.78 lbs (5.80 kg) |
