Fortinet FortiSwitch 448E-POE (FS-448E-POE) – Thiết bị chuyển mạch
Liên hệ
- 48 cổng GE RJ45
- 4x 10 GE SFP +
- 48 cổng PoE+
Mô tả
Thuộc Tính
Description
Fortinet FortiSwitch 448E-POE (FS-448E-POE) là thiết bị chuyển mạch tương thích với bộ điều khiển switch Fortinet FortiGate Layer 2/3 với 48 cổng GE RJ45, 4x 10 GE SFP +, 48 cổng PoE+ với giới hạn tối đa 421 W.
Xem thêm:
Thông số kỹ thuật của Fortinet FortiSwitch 448E-POE (FS-448E-POE) – Thiết bị chuyển mạch
| Mã sản phẩm | FS-448E-POE |
| Hardware Specifications | |
| Total Network Interfaces | 48 x GE RJ45 and 4 x 10GE SFP+ ports Note: SFP+ ports are compatible with 1 GE SFP |
| Dedicated Management 10/100 Port | 1 |
| RJ-45 Serial Console Port | 1 |
| Form Factor | 1 RU Rack Mount |
| Power over Ethernet (PoE) Ports | 48 (802.3af/at) |
| PoE Power Budget | 421 W |
| Mean Time Between Failures | > 10 years |
| System Specifications | |
| Switching Capacity (Duplex) | 176 Gbps |
| Packets Per Second (Duplex) | 262 Mpps |
| MAC Address Storage | 32 K |
| Network Latency | <1µs |
| VLANs Supported | 4 K |
| Link Aggregation Group Size | 8 |
| Total Link Aggregation Groups | Up to number of ports |
| Packet Buffers | 4 MB |
| DRAM | 1 GB DDR4 |
| FLASH | 256 MB |
| ACL | 1.5k |
| Spanning Tree Instances | 16 |
| Route Entries (IPv4/IPv6) | 16k/8k |
| Host Entries | 16k |
| Dimensions | |
| Height x Depth x Width (inches) | 1.73 x 16.1 x 17.3 |
| Height x Depth x Width (mm) | 44 x 410 x 440 |
| Weight | 13.8 lbs (6.26 kg) |
| Environment | |
| Power Required | 100–240V AC, 50–60 Hz |
| Power Supply | AC built in |
| Redundant Power | Redundant AC |
| Power Consumption (Average / Maximum) | 440.12 W / 442.234 W |
| Heat Dissipation | 163.066 BTU/h |
| Operating Temperature | 32–122°F (0–50°C) |
| Storage Temperature | -4–158°F (-20–70°C) |
| Humidity | 10–90% non-condensing |
| Air-Flow Direction | Side-to-back |
| Noise Level | 38.3 dBA |
| Certification and Compliance | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
