Fortinet FortiSwitch 424E-FIBER (FS-424E-Fiber) – Thiết bị chuyển mạch
Liên hệ
- 24x GE SFP ports
- 4x 10GE SFP+ ports
- 1 RU Rack Mount
- Redundant AC
Mô tả
Thuộc Tính
Description
Fortinet FortiSwitch 424E-FIBER (FS-424E-Fiber) là thiết bị chuyển mạch Layer 2/3 và tương thích với bộ điều khiển switch Fortinet FortiGate. Nó có 24x GE SFP và 4x 10 GE SFP+ Uplinks
- 24x GE SFP ports
- 4x 10GE SFP+ ports
- 1 RU Rack Mount
- Redundant AC
Xem thêm:
Thông số kỹ thuật của Fortinet FortiSwitch 424E-FIBER (FS-424E-Fiber) – Thiết bị chuyển mạch
| Mã sản phẩm | FS-424E-Fiber |
| Hardware Specifications | |
| Total Network Interfaces | 24x GE SFP and 4x 10GE SFP+ ports Note: SFP+ ports are compatlble with 1 GE SFP |
| Dedicated Management 10/100/1000 Ports | 1 |
| RJ-45 Serial Console Port | 1 |
| Form Factor | 1 RU Rack Mount |
| Mean Time Between Failures | > 10 years |
| System Specifications | |
| Switching Capacity | 128 Gbps |
| Packets Per Second | 204 Mpps |
| MAC Address Storage | 32 K |
| Network Latency | < 1µs |
| VLANs Supported | 4 K |
| Link Aggregation Group Size | 8 |
| Total Link Aggregation Groups | Up to number of ports |
| Packet Buffers | 4 MB |
| DRAM | 1 GB DDR4 |
| FLASH | 256 MB |
| ACL | 1.5k |
| Spanning Tree Instances | 16 |
| Route Entries (IPv4/IPv6) | 16k/8k |
| Host Entries | 16k |
| Dimensions | |
| Height x Width x Length (inches) | 1.75 x 7.87 x 17.3 |
| Height x Width x Length (mm) | 44 x 200 x 440 |
| Weight | 5.62 lbs (2.55 kg) |
| Environment | |
| Power Required | 100–240V AC, 50/60 Hz |
| Power Supply | AC built in |
| Redundant Power | Redundant AC |
| Power Consumption (Average / Maximum) | 36 W / 38 W |
| Heat Dissipation | 132.5 BTU/h |
| Operating Temperature | 32–113°F (0–45°C) |
| Storage Temperature | -4–158°F (-20–70°C) |
| Humidity | 5–95% non-condensing |
| Air-Flow Direction | side-to-back |
| Noise Level | 32.8 dBA |
| Certification and Compliance | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
