FortiSwitch 1024D (FS-1024D) – Thiết bị chuyển mạch Fortinet
Liên hệ
- 24x GE/10 GE SFP/SFP+.
- Bộ nguồn AC kép
Mô tả
Thuộc Tính
Description
Fortinet FortiSwitch 1024D (FS-1024D) là thiết bị chuyển mạch Layer 2/3 với 24x GE/10 GE SFP/SFP+. Bộ nguồn AC kép
Xem thêm: FortiSwitch-1024D-QuickStart
Thông số kỹ thuật của FortiSwitch 1024D (FS-1024D) – Thiết bị chuyển mạch Fortinet
|
Mã sản phẩm |
FS-1024D |
| Hardware Specifications | |
| Total Network Interfaces | 24 x GE/10 GE SFP+ ports |
| 10/100/1000 Service Ports | 1 |
| RJ-45 Serial Console Port | 1 |
| Form Factor | 1 RU Rack Mount |
| System Specifications | |
| Switching Capacity (Duplex) | 480 Gbps |
| Packets Per Second (Duplex) | 714 Mpps |
| MAC Address Storage | 128 K |
| Network Latency | < 800ns |
| VLANs Supported | 4 K |
| IPv4/IPv6 Routing | Yes |
| Link Aggregation Group Size | Up to 24 |
| Total Link Aggregation Groups | Up to number of ports |
| Queues/Port | 8 |
| Packet Buffers | 9 MB |
| DRAM | 2 GB DDR4 |
| FLASH | 128 MB |
| Dimensions | |
| Height x Depth x Width (inches) | 1.71 x 18.11 x 17.26 |
| Height x Depth x Width (mm) | 43.5 x 460 x 438.5 |
| Weight | 17.62 lbs (8 kg) |
| Environment | |
| Power Required | 100–240V AC, 50–60 Hz |
| Power Supply | Dual hot swappable AC |
| Power Consumption (Average / Maximum) | up to 140 W |
| Heat Dissipation | 163.1 BTU/h |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -13–158°F (-25–70°C) |
| Humidity | 10–90% non-condensing |
| Certification and Compliance | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
