Cisco FPR1010-FTD-HA-BUN – Thiết bị tường lửa
-
Cổng kết nối: 8 x RJ-45 (bao gồm 2 cổng POE+)
-
Cổng quản lý mạng tích hợp: 1 x Giga Ethernet port (RJ-45)
-
Cổng nối tiếp (Serial port): 1 x RJ-45 console
-
Cổng USB: 1 x USB 3.0 Type-A (500mA)
Description
Cisco FPR1010-FTD-HA-BUN là thiết bị tường lửa hỗ trợ giao thức bảo mật IPSec VPN, với số lượng kết nối IPsec VPN Peer tối đa là 75 và thông lượng tối đa (IPSec VPN throughput) đạt 300 Mbps. Thiết bị này hoạt động tối ưu cho khoảng 50 người dùng.
-
Cổng kết nối: 8 x RJ-45 (bao gồm 2 cổng POE+)
-
Cổng quản lý mạng tích hợp: 1 x Giga Ethernet port (RJ-45)
-
Cổng nối tiếp (Serial port): 1 x RJ-45 console
-
Cổng USB: 1 x USB 3.0 Type-A (500mA)
-
Lưu trữ: 1 x 200 GB
-
Cấu hình nguồn điện: +12V và -53.5V
-
Điện áp vào AC: 100 đến 240V AC
-
Trọng lượng: 3 lb (1.36 kg)
Thông số kỹ thuật của Cisco FPR1010-FTD-HA-BUN – Thiết bị tường lửa
Part Number | FPR1010-FTD-HA-BUN |
Interfaces | 8 x RJ-45 (Includes 2 POE+ capable ports) |
Integrated network management ports | 1 x Giga Ethernet port (RJ-45) |
Serial port | 1 x RJ-45 console |
USB | 1 x USB 3.0 Type-A (500mA) |
Storage | 1 x 200 GB |
Power supply configuration | +12V and -53.5V |
AC input voltage | 100 to 240V AC |
Weight | 3 lb (1.36 kg) |
Rack mountable | Yes. Separate kit must be ordered. |
Throughput: Firewall (FW) + Application Visibility and Control (AVC) + Intrusion Prevention System (IPS) (1024B) | 650 Mbps |
Maximum concurrent sessions, with AVC | 100K |
Maximum new connections per second, with AVC | 6K |
Transport Layer Security (TLS) | 150 Mbps |
Throughput: NGIPS (1024B) | 650 Mbps |
IPSec VPN throughput (1024B TCP w/Fastpath) | 300 Mbps |
Maximum VPN Peers | 75 |
Cisco Firepower Device Manager (local management) | Yes |
Stateful inspection firewall throughput1 | 2 Gbps |
Stateful inspection firewall throughput (multiprotocol)2 | 1.4 Gbps |
Concurrent firewall connections | 100,000 |
Firewall latency (UDP 64B microseconds) | - |
New connections per second | 25,000 |
IPsec VPN throughput (450B UDP L2L test) | 500 Mbps |
Maximum VPN Peers | 75 |
Security contexts (included; maximum) | NA |
High availability | Active/active and Active/standby |
Additional information
Thương hiệu | |
---|---|
Bảo hành | 12 tháng |
