Fortinet FortiAP U431F (FAP-U431F) – Bộ thu phát wifi
- 4×4 Wi-Fi 6 (802.11ax)
- Điểm phát wifi không dây trong nhà: Tri radio
- Ăng-ten bên trong
- 1 x 2.5 GE & 1 x cổng GE RJ4
Description
Fortinet FortiAP U433F là bộ thu phát wifi trong nhà Wi-Fi 6 (802.11ax) cấp doanh nghiệp cung cấp ba đài. Thiết bị cung cấp OFDMA, cổng Ethernet 2,5 Gigabit cộng với cổng Ethernet 1 Gbps bổ sung để đa dạng PoE. Thiết bị có thể được cấu hình để truy cập băng tần kép 5 GHz trong khi vẫn cung cấp vùng phủ sóng cho các thiết bị trên băng tần 2,4 GHz hoặc có thể được định cấu hình để cung cấp chức năng quét chuyên dụng. Đài BLE tích hợp có thể được sử dụng cho đèn hiệu và ứng dụng định vị.
- 802.11ax | Tri-Radio 5 GHz + 5 GHz + 2,4 GHz hoặc 5 GHz + 2,4 GHz + quét | 10 Anten bên trong
- MIMO 4×4 | Lên tới 4.804 Mbps + 4.804 Mbps + 300 Mbps
Xem thêm: fortiap-u-series-datasheet
Thông số kỹ thuật của Fortinet FortiAP U431F (FAP-U431F) – Bộ thu phát wifi
Mã sản phẩm | FAP-U431F |
Hardware | |
Hardware Type | Indoor AP |
Number of Radios | 3 + 1 BLE |
Number of Antennas | 10 Internal + 1 BLE Interna |
Antenna Type and Peak Gain | PIFA: 4 dBi for 2.4 GHz, 6 dBi for 5 GHz |
Frequency Bands (GHz) | 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
Radio 1 Capabilities | 5.0 GHz a/n/ac/ax (4x4:4 stream) 20/40/80/160 MHz (64/256/1024 QAM) |
Radio 2 Capabilities | 2.4 GHz or 5.0 GHz (high band) a/b/g/n/ac/ax (4x4:4 stream) 20/40/80/160 MHz (64/256/1024 QAM) |
Radio 3 Capabilities | 2.4/5.0 GHz dual band b/g/n/ac (2x2:2 stream) 20/40 MHz (64 QAM) |
Maximum Data Rate |
Radio 1: up to 4,804 Mbps
Radio 2: up to 4,804 Mbps
Radio 3: up to 300 Mbps
|
Bluetooth Low Energy Radio | Bluetooth scanning and iBeacon advertisement @ 4 dBm max TX power |
Interfaces | 1x 10/100/1000/2500 Base-T RJ45, 1x 10/100/1000 Base-T RJ45, 1x Type A USB, 1x RS-232 RJ45 Serial Port |
Power over Ethernet (PoE) | Dual redundant PoE power ports with support for IEEE 802.3at or dual 802.3af power |
Simultaneous SSIDs | Up to 16 (14 if background scanning enabled) |
EAP Type(s) | EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST |
User/Device Authentication | WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blocklist and allowlist |
Maximum Tx Power (Conducted) |
• Radio 1: 5 GHz: 24 dBm / 251 mW (4 chains combined)
• Radio 2: 2.4 GHz: 26 dBm / 398 mW (4 chains combined)* 5 GHz: 24 dBm / 251 mW (4 chains combined)
• Radio 3: 2.4 GHz: 22 dBm / 158 mW (2 chains combined)
|
Kensington Lock | Yes |
IEEE Standards | 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11w, 802.11ac, 802.1Q, 802.1X, 802.3ad, 802.3af, 802.3at, 802.3az, 802.11ax, 802.3bz, Wi-Fi 6 |
SSID Types Supported | Local-Bridge, Mesh, & Tunnel |
Per Radio Client Capacity | Up to 512 per Radio1 and Radio2 |
Cellular Co-existence | Yes |
Reset Button | Yes |
Threat Protection Capable | Yes |
LED Off Mode | Yes |
Advanced 802.11 Features | |
Transmit Beam Forming (TxBF) | Yes |
Low-Density Parity Check (LDPC) Encoding | Yes |
Maximum Likelihood Demodulation (MLD) | Yes |
Maximum Ratio Combining (MRC) | Yes |
A-MPDU and A-MSDU Packet Aggregation | Yes |
OFMDA | Yes (UL and DL) |
2.4 GHz OFDMA | Yes |
Spatial Reuse (BSS Coloring) | Yes |
HE-MU-MIMO | Yes |
UL-MU-MIMO 802.11ax mode | Yes |
UL-MU-MIMO 802.11ac mode | No |
DL-MU-MIMO | Yes |
Enhanced Target Wake Time (TWT) | Yes |
ZeroWait DFS /Agile DFS | Yes |
Wireless Monitoring Capabilities | |
Rogue Scan Radio Modes | Background, Dedicated |
WIPS / WIDS Radio Modes | Background, Dedicated (recommended) |
Packet Sniffer Mode | Yes |
Spectrum Analyzer | Yes |
Dimensions | |
Length x Width x Height | 8.46 x 8.46 x 2.26 inches (215 x 215 x 57.5 mm) |
Weight | 1.0 lb (0.453 kg) |
Package (shipping) Weight | 1.8 lbs (0.82 kg) |
Mounting Options | Ceiling, T-Rail, and Wall |
Included Accessories | Mount kits for Ceiling, T-Rail, and Wall |
Environment | |
Power Supply | GPI-130, or 2x GPI-115 GPI-130, or 2x GPI-115, or AC adapter SP-FAP43F-PA-X-5 |
Power Consumption (Maximum) | 24.5 W |
Humidity |
10–90% Non-Condensed
5–90% Condensed
|
Operating / Storage Temperature | 32–122°F (0–50°C) / -31–158°F (-35–70°C) |
Directives | Low Voltage Directive • RoHS |
UL2043 Plenum Material | Yes |
Mean Time Between Failures | >30 Years |
Hit-less PoE Failover | Yes (802.3at only) |
Certifications | |
Wi-Fi Alliance Certified | Yes |
DFS | FCC, IC, CE, Japan, Taiwan, Korea, Brazil |
