| Mã sản phẩm |
FAP-431G |
| Hardware |
| Hardware Type |
Indoor AP |
| Number of Radios |
3 + 1 BLE |
| Number of Antennas |
Internal
x4 Dual band Wi-Fi
x4 Tri-band Wi-Fi & Scanning
1 Single band 2.4GHz BLE/ZigBee |
| Antenna Type and Peak Gain |
PIFA antenna.
Dual band: 4.0 dBi for 2.4GHz, 5.6 dBi for 5 GHz
Tr-band: 4.0 dBi for 2.4GHz, 6.0 dBi for 5 GHz & 5.7dBi for 6GHz band
BLE antenna: 5.1dBi for 2.4Ghz |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850, 5.925–6.425, 6.425–6.525, 6.525–7, 5.925–6.875, 6.875–7.125 |
| Maximum Data Rate |
Radio 1: up to 1148 Mbps
Radio 2: up to 2402 Mbps
Radio 3: up to 4804 Mbps |
| Bluetooth Low Energy Radio |
Bluetooth scanning and iBeacon advertizement @10 dBm max TX power |
| Interfaces |
x2 100/1000/2500/5000 Base-T RJ45
1 Type 3.0 USB
1 RS-232 RJ45 Serial Port |
| Power over Ethernet (PoE) |
1 802.3bt PoE default or x2 802.3at PoE (Dual PoE current sharing) |
| Simultaneous SSIDs |
Up to 24 |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blocklist and allowlist |
| Maximum Tx Power |
Radio 1: 2.4GHz: 27 dBm / 501 mW (4 chains combined)
Radio 2: 5GHz: 26 dBm / 400 mW (4 chains combined)
Radio 3: 6GHz: 24 dBm 251 mW (4 chains combined @ 160MHz BW) |
| SSID Types Supported |
Local-Bridge, Mesh, and Tunnel |
| Per Radio Client Capacity |
Up to 512 clients per radio (Radio1, Radio2 and Radio3) |
| Dimensions |
| Length x Width x Height |
8.85 x 8.85 x 2.12 inches (225.0 x 225.0 x 54.0 mm) |
| Weight |
3.05 lbs (1.4 kg) |
| Package (shipping) Weight |
5.25 lbs (2.4 kg) |
| Mounting Options |
Ceiling, T-Rail, and Wall |
| Included Accessories |
Standard Mounting kit for Ceiling, T-Rail and Wall |
| Environment |
| Power Supply |
SP-FAP400-PA-XX or 802.3bt PoE.
Also supports Dual PoE sharing with 2x 802.3at PoE (GPI-130) or Single 802.at PoE (GPI-130) with No USB and reduced Transmit power |
| Power Consumption (Max) |
31.7 Watts |
| Humidity |
5–90% Non-Condensing |
| Operating / Storage Temp. |
32°–122°F (0° - 50°C) / -22°–158°F (-30°–70°C) |
