| FAP-831F |
| Radio 1 Capabilities |
Frequency Band: 2.4 GHz
Channel width: 20/40 MHz
Modulation: BPSK, QPSK, QAM64
MIMO chains: 4x4 service |
| Radio 2 Capabilities |
Frequency Band: 5.0 GHz
Channel width: 20/40/80/80+80/160MHz
Modulation: BPSK, QPSK, QAM64, QAM256, and QAM1024
Mimo chains: 8x8 service in mode 1 or 4x4+4x4 service in mode 2 |
| Radio 3 Capabilities |
Frequency band: 2.4/5.0 GHz
MIMO chains: 1x1 frequency scanning |
| User/Device Authentication |
WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blocklist and allowlist |
| Maximum Tx Powerr (Conducted) |
- Radio 1: 2.4 GHz 27 dBm / 500 mW (4 chains combined)
- Radio 2: 5 GHz 25.5 dBm / 354 mW (4 chains combined)
- Radio 3: NA |
| Kensington Lock |
✔ |
| IEEE Standards |
802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i,802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11ac, 802.11ax (Wi-Fi 6), 802.1Q, 802.1X, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3bz |
| Cellular Co-existence |
✔ |
| LED Off Mode |
✔ |
| Advanced 802.11 Features |
| OFDMA |
✔ (UL and DL) |
| Spatial Reuse (BSS Coloring) |
✔ |
| UL-MU-MIMO 802.11ax mode |
✔ |
| DL-MU-MIMO |
✔ |
| Enhanced Target Wake Time (TWT) |
✔ |
| ZeroWait DFS/Agile DFS |
✔ |
| Wireless Monitoring Capabilities |
| Rogue Scan Radio Modes |
Dedicated |
| WIPS / WIDS Radio Modes |
Dedicated |
| Packet Sniffer Mode |
✔ |
| Spectrum Analyzer |
✔ |
| PoE Mode |
| Single 5G |
DC/2at --> Full Mode ; Radios will be in (8x8|4x4) & USB Enabled 1at/2af --> High Mode ; Radios will be in (8x8|4x4) & USB Disabled 1af --> Low Mode ; Radios will be [2x2|2x2], Tx Power 10 dBm & USB Disabled |
| Dual 5G |
DC/2at --> Full Mode ; Radios will be in [4x4|4x4|4x4] & USB Enabled 1at/2af --> High Mode ; Radios will be in [4x4|4x4|4x4] & USB Disabled 1af --> Low Mode ; Radios will be [2x2|2x2|2x2], Tx Power 10 dBm & USB Disabled |
| Directives |
Low Voltage Directive • RoHS |
| UL2043 Plenum Material |
✖ |
| Mean Time Between Failures |
>10 Years |
| Surge Protection Built In |
✔ |
