Fortinet FortiAP 223E (FAP-223E) – Bộ phát wifi
Liên hệ
- Phát wifi không dây trong nhà
- Radio kép (802.11 b/g/n và 802.11 a/n/ac Wave 2, 2×2 MU-MIMO)
- Bao gồm ăng-ten bên ngoài
- 1 x 10/100/1000 RJ45 cổng BT/BLE.
- Bao gồm bộ giá treo trần/tường.
Mô tả
Thuộc Tính
Description
FortiNet FortiAP 223E (FAP-223E) là Bộ phát wifi không dây trong nhà, Radio kép (802.11 b/g/n và 802.11 a/n/ac Wave 2, 2×2 MU-MIMO), bao gồm ăng-ten bên ngoài, 1 x 10/100/1000 RJ45 cổng BT/BLE. Bao gồm bộ giá treo trần/tường.
Xem thêm: fortiap-series-datasheet
Thông số kỹ thuật của Fortinet FortiAP 223E (FAP-223E) – Bộ phát wifi
| Mã sản phẩm | FAP-223E |
| Hardware | |
| Hardware Type | Indoor |
| Number of Radios | 2 |
| Number of Antennas | 4 RP-SMA External |
| Peak Antenna Gain | 4 dBi for 2.4 GHz, 5 dBi for 5 GHz |
| Frequency Bands (GHz) | 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Frequency of Radio 1 | 2.4 GHz b/g/n (2x2:2 stream) 20/40 MHz (256 QAM) |
| Frequency of Radio 2 | 5 GHz a/n/ac (2x2:2 stream) 20/40/80 MHz (256 QAM) |
| Maximum Data Rate | Radio 1: up to 400 Mbps Radio 2: up to 867 Mbps |
| Ethernet Ports | 1x GE RJ45 |
| USB Port | 1x Type A |
| Serial Console Port | - |
| Power over Ethernet (PoE) | IEEE 802.3af |
| Simultaneous SSIDs | 16 (14 if background scanning enabled) |
| EAP Type(s) | EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication | WPA™ and WPA2™ with 802.1x or Preshared key, WEP and Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power | 25 dBm (316 mW) @ 2.4 GHz* 23 dBm (200 mW) @ 5 GHz |
| Physical Security | Kensington Lock |
| IEEE Specifications | 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.1x, 802.11ac, 802.3af, 802.3az |
| FortiPresence Capable | Yes |
| Wireless Mesh Capable | Yes |
| Per Radio Client Capacity | Up to 512 |
| Advanced 802.11 Features | |
| 802.11ac Wave 2 MU-MIMO | Yes |
| Transmit Beam Forming (TxBF) | Yes |
| Low-Density Parity Check (LDPC) Encoding | Yes |
| Maximum Likelihood Demodulation (MLD) | Yes |
| Maximum Ratio Combining (MRC) | Yes |
| 802.11ac 20/40/80 MHz Channel | Yes |
| A-MPDU and A-MSDU Packet Aggregation | Yes |
| MIMO Power Save | Yes |
| Short Guard Interval | Yes |
| WME Multimedia Extensions | Yes |
| Wireless Monitoring Capabilities | |
| Frequencies Scanned | 2.4 and 5 GHz |
| Background Scan with Client Access on 2.4 and 5 GHz | Yes |
| Full-time Scan as Dedicated Monitor | Yes |
| Full-time Scan with Client Access on 5G GHz | No in AP mode |
| Dimensions | |
| Diameter x Height | 6.3 x 1.85 inches (160 x 47 mm) |
| Weight | 1.1 lb (0.5 kg) |
| Package (shipping) Weight | 5.3 lb (2.4 kg) |
| Mounting Options | Ceiling, T-Rail and wall |
| Included Accessories | Ceiling, T-Rail and Wall mount kit and 8 dipole antennas (AC power adapter sold seperately) |
| Environment | |
| Power Supply | Adapter Input: 100–240V, 50/60Hz, 0.9A Maximum Output: 12V DC, 3A |
| Power Consumption (Avg.) | 10.25 W |
| Power Consumption (Max.) | 12.36 W |
| Humidity | 5–90% non condensing |
| Operating Temperature | -4–122°F (-20–50°C) |
| Storage Temperature | -40–158°F (-40–70°C) |
| Directives | Low Voltage Directive • RoHS |
| UL2043 Plenum Material | Yes |
| Mean Time Between Failures | >30 Years |
| Certifications | |
| WiFi Alliance Certified | Yes |
| DFS Certified for Europe | Yes |
| Hotspot 2.0 Certified | Yes |
