Authentication and security |
- Wi-Fi Protected Access 2 and 3 (WPA2 and WPA3)
- 802.1X, RADIUS Authentication, Authorization, and Accounting (AAA)
- 802.11r and 802.11i
|
Maximum clients |
- Maximum number of associated wireless clients: 200 per Wi-Fi radio, for a total of 400 clients per access point |
Max # of Mesh Extenders |
- Maximum number of associated Cisco Business mesh extenders: 25 per Access Point, up to 8 hops |
802.11ac |
- 2x2 single-user/multi-user MIMO with two spatial streams, up to 867 Mbps
- 20-, 40-, and 80-MHz channels
- Dynamic Frequency Selection (DFS)
|
Data rates supported |
802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz: 6.5 to 300 Mbps (MCS0-MCS15, HT 20/40)
802.11ac data rates on 5 GHz: 6.5 to 867 Mbps (MCS0-MCS9) |
Available transmit power settings |
2.4 GHz
- Up to 20 dBm
5 GHz
- Up to 20 dBm
|
Integrated antennas |
- 2.4 GHz, gain 2 dBi
- 5 GHz, gain 3 dBi
|
Interfaces |
- 1x Gigabit Ethernet uplink (10/100/1000BASE-T autosensing), PoE
- 3x Gigabit Ethernet local ports (10/100/1000BASE-T), including one PoE out port:
PoE out provides 802.3af (Class 0) when access point is powered by 802.3at, or no output when powered by 802.3af
- One passive pass-through port, RJ-45 (back to bottom) |
Indicators |
- Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors |
Dimensions (W x L x H) |
- Access point (without mounting bracket): 3.5 x 5.5 x 1.25 in. (89 x 140 x 31.5 mm) |
Weight |
- Access point without mounting bracket or any other accessories: 10 oz (400 g) |
Environmental |
Operating
- Temperature: 32° to 104°F (0° to 50°C)
- Humidity: 10% to 90% (noncondensing)
- Maximum altitude: 9843 ft (3000 m) at 40°C
Nonoperating (storage and transportation)
- Temperature: –22° to 158°F (-30° to 70°C)
- Humidity: 10% to 90% (noncondensing)
- Maximum altitude: 15,000 ft (4500 m) at 25°C
|
System |
- 1 GB DRAM
- 256 MB Flash
- 710-MHz quad core processor
|
Powering options |
- 802.3af/at Ethernet switch; a Cisco Business switch with PoE is recommended
- Optional Cisco Business PoE injector
|
Power draw |
- 8.5W (maximum, on PoE) |
Physical security |
- Torx security screw, included with the access point
- Kensington lock slot to lock device to mounting bracket
|
Mounting and physical security |
- Bracket is included with the access point |
Warranty |
Cisco Business limited lifetime hardware warranty
Free software updates, no service contract required |
